6. Check that the correct size cuff is being applied.
7. Check that the cuff is not leaking air.
8. Check that the hose connections are not damaged or loose.
9. Take another BP reading.
Status Codes: 800, 900, 910, 970, 980, or 990
Problem: System error
Solutions:
1. Take another measurement.
2. If this is unsuccessful, power down, then power up the unit using the power button on the
right side of the unit. If the error does not recur immediately, take another measurement.
3. If the error recurs, remove power from the unit (unplug any power supplies and remove
the battery, if there is one), then reconnect the power. If the error does not recur
immediately, take another measurement.
4. If the error recurs, contact ADC or an authorized service center.
Troubleshooting - Temperature Module
Status Code: 5
Problem: Temperature probe missing or outside of well
Solutions:
1. Remove and then place the probe in the well.
2. Ensure that the temperature well (the rear portion of the temperature module) is well
seated on the display. Along the top of the module, the edge of the well should be flush
with the display. Remove and carefully slide the well onto the display.
When properly fixed, the error should no longer be displayed. Take a new measurement.
Status Code: 10
Problem: Defective temperature probe
Solutions:
1. Remove and then place the probe in the well.
2. Ensure that the temperature well (the rear portion of the temperature module) is well
seated on the display. Along the top of the module, the edge of the well should be flush
with the display. Remove and carefully slide the well onto the display.
When properly fixed, the error should no longer be displayed. Turn the device off. After it
has shut down, turn it on. The error should no longer be displayed. Take a new measurement.
Status Code: 15
Problem: Stuck button
Solution: Depress the Temperature units select button and/or the Temperature mode select
button until the button becomes unstuck. When the button is unstuck, the error will no longer be
displayed. If you cannot un-stick the button, contact ADC or an authorized service center.
