27
MEASURING OXYGEN SATURATION WITH THE
ADVIEW
The ADview optional pulse oximeter module measures functional oxygen saturation ranging from 40% to
100%. A signal strength display assists the clinician in the proper placement of the sensor.
The ADview is a spot check device and is not used for patient monitoring. Therefore,
there are no SpO
2
alarms.
Steps for measuring functional oxygen saturation:
• Prepping the patient and affixing the sensor
• Taking a reading
Prepping the Patient
Selecting the Right Sensor
Your choice of sensor is affected by many factors including:
• Patient’s body weight
• Patient activity
• Infection control concerns
For most patients greater than 30kg, use an adult sensor; for patients 10-50kg, a
pediatric sensor may provide better fit.
Protecting Your Pulse Oximetry Sensors
In addition to the safety instructions for your ADview, here are some additional tips on caring for the sensor
of the optional pulse oximetry module:
• To prevent damage, do not autoclave or immerse the sensor in liquid.
• For peak performance and accurate measurements, do not expose the sensor to excessive ambient
light, electromagnetic interference, dysfunctional hemoglobin, low perfusion, intravascular dyes,
finger nail polish and long or artificial finger nails.
• Do not use a damaged sensor as it may cause patient injury or equipment failure.
• The use of this sensor is contraindicated in patients with allergies to adhesive tape.
Guidelines for Use
