American Diagnostic Corporation (ADC) ADview Modular Diagnostic Station User Manual
Page 14
4
Buttons on the main BP module
Button Functionality for the BP Module
Button
Device Status
Action
Result
Automatic
Idle
Select for less than 2
seconds
Start an automatic BP measurement.
Select for 2 to 5 seconds
Redisplay last measurement values for
all modules.
Select for more than 5
seconds
Clear last measurement values for all
modules.
Taking an
automatic or
Sphygmode BP
Select
Aborts the BP measurement in
progress.
In Calibration
Check mode
Select
Device exits Calibration Check mode
and is ready to take measurements.
Sphygmode
Manual
Idle
Select
Inflates the cuff as long as the button
is selected.
Taking a
Sphygmode BP
Select
Re-inflates the cuff as long as the
button is selected.
Taking an
automatic BP
Select
Aborts the BP measurement in
progress.
In Calibration
Check mode
Select
Device exits Calibration Check mode
and is ready to take measurements.
Power
Power off
Select
Turns on the device.
Power on
Select
Turns off the device.
Automatic +
Power
Power off
Hold the Automatic
button down while
selecting the Power
button.
Device enters the Calibration Check
mode.
Sphygmode
Manual +
Power
Power off
Hold the Sphygmode
button down while
selecting the Power
button.
Device enables/disables MAP mode.
BP display
