5-2 - DeviceNet Compatible Network Unit DL-DN1 User's Manual -
5
Ap
pend
ix
5-1
Connecting with Sensor Amplifiers
As of July 15, 2010
*1 Cannot be connected to the GT-70 series.
*2 Cannot be connected to the panel mounting type.
*3 For the large display type, up to 11 sensor heads can be connected by adding
head expansion boards to a main unit.
Connectable Sensor Amplifiers
Name Amplifier form Main unit Expansion unit
Maximum number
of connectable
units
High-precision
contact type digital
sensor
GT2 series
DIN rail
mounting type GT2-71(M)(C)N
GT2-71(M)(C)P GT2-72(C)N
GT2-72(C)P 15 (1 main unit, 14
expansion units)
Panel
mounting type GT2-75N
GT2-75P GT2-76N
GT2-76P 15 (1 main unit, 14
expansion units)
Large display
type GT2-100N
GT2-100P
- 1 (1 main unit)
*3
General-purpose
contact type digital
sensor
GT-70A series
*1
DIN rail
mounting type GT-71A
GT-71AP GT-72A
GT-72AP 10 (1 main unit, 9
expansion units)
Panel
mounting type GT-75A
GT-75AP GT-76A
GT-76AP 10 (1 main unit, 9
expansion units)
Thrubeam laser
sensor
IG series
DIN rail
mounting type
IG-1000 IG-1050
4 (1 main unit, 3
expansion units)
Panel
mounting type
IG-1500 IG-1550
Thrubeam Type Laser
Detection Sensor
IB series
DIN rail
mounting type
IB-1000 IB-1050
4 (1 main unit, 3
expansion units)
Panel mounting
type
IB-1500 IB-1550
Electromagnetic
digital flow sensor
FD-MH series
*2
DIN rail
mounting type FD-MA1(A)
FD-MA1(A)P FD-MA2(A)
FD-MA2(A)P 10 (1 main unit, 9
expansion units)
Coriolis digital flow
sensor
FD-S series
*2
DIN rail
mounting type FD-SA1N(A)
FD-SA1P(A) FD-SA2N(A)
FD-SA2P(A) 4 (1 main unit, 3
expansion units)
