The error content of the sensor amplifier can be checked by noting the ON/OFF
state of each bit.
OFF (0): No error; ON (1): Error
More than one error may occur simultaneously. For details of each error, refer to
the IB Series User's Manual.
*2
Details of output status can be checked by noting the ON/OFF state of each bit.
*3
Use this parameter in combination with the comparator value property or with
the comparator value "invalid," "over," or "under."
*4
If the read data has one of the values listed below, it has a different meaning
than the comparator value.
In % mode:
999.99: The value is above the upper limit of the display range.
-999.99: The value is -999.98 or below the lower limit of the display range.
-999.98: The value is "-----" (invalid).
+1000.00: The sensor amplifier is in error.
In size mode:
+99.999: The value is above the upper limit of the display range.
-99.999: The value is -99.999 or below the lower limit of the display range.
-99.998: The value is "-----" (invalid).
+100,000: The sensor amplifier is in error.
Nx10+6
064
Group-6 entry count
R
11
65
Product code
R
Main unit: 4020
Expansion unit: 4021
66
Reserved
67
Transmitter head model
R
0: Sensor head is not connected, or light
receiver is connected.
1: Light transmitter of IB-01 is connected.
2: Light transmitter of IB-05 is connected.
3: Light transmitter of IB-10 is connected.
4: Light transmitter of IB-30 is connected.
68
Receiver head model
R
0: Sensor head is not connected, or light
transmitter is connected.
1: Light receiver of IB-01 is connected.
2: Light receiver of IB-05 is connected.
3: Light receiver of IB-10 is connected.
4: Light receiver of IB-30 is connected.
69 to
6B
Reserved
6C
Product name 1
*19
R
Main unit: "IB-1"
Expansion unit: "IB-1"
6D
Product name 2
*19
R
Main unit: "000/"
Expansion unit: "050/"
6E
Product name 3
*19
R
Main unit: "1500"
Expansion unit: "1550"
6F
Product name 4
*19
R
Main unit: ""
Expansion unit: ""
70 to
83
Reserved
8C
Prroduct name (16-byte reading)
*20
Main unit: "IB-1000/1500"
Expansion unit: "IB-1050/1550"
InstID
(DEC)
AttrID
(HEX)
Name
Description Attribute
Default
value
Parameter range
