3-3 Explicit Messaging
3-31
- DeviceNet Compatible Network Unit DL-DN1 User's Manual -
3
Comm
un
ica
ti
ng wit
h th
e
IB
Ser
ies
Nx10+1
71 to
75
Reserved
76
Laser emission stop status
R
0: Laser emitting
1: Laser stopped
77
Abnormal setting
*9
R
㪇㪑㩷Normal setting
1: Abnormal setting
78
External input status
*22
R
0 to 15
79
EEPROM writing result
*10
R
1
0: Writing
1: Normal termination
2: Abnormal termination
7A
Zero shift execution result
*11
R
1
0: Executing
1: Normal termination
2: Execution impossible
7B
Reset execution result
*11
R
1
0: Executing
1: Normal termination
2: Execution impossible
7C
System parameter current state
*12
R
0
Main unit: 0 - 9
Expansion unit: 0 - 1
7D
Reserved
7E
Reference light registration result
R
1
0: Executing
1: Normal termination
2: Light insufficient error
3: Interfering light error
7F
Adjust result
*23
R
1
0: Executing
1: Normal termination
2: Light insufficient error
3: Excess light error
80
Tuning result
*13
R
1
0: Executing
1: Normal termination
2: Execution impossible
81
Correction result
*24
R
1
0: Executing
1: Normal termination
2: Execution impossible
82 to
83
Reserved
Nx10+2
64
Group-2 entry count
R
12
65
HIGH setting value (Bank 0)
*7
R/W
20.00 -999.99 to +999.99
66
LOW setting value (Bank 0)
*7
R/W
10.00 -999.99 to +999.99
67
Shift target value (Bank 0)
*7
R/W
0.00 -999.99 to +999.99
68
HIGH setting value (Bank 1)
*7
R/W
20.00 -999.99 to +999.99
69
LOW setting value (Bank 1)
*7
R/W
10.00 -999.99 to +999.99
6A
Shift target value (Bank 1)
*7
R/W
0.00 -999.99 to +999.99
6B
HIGH setting value (Bank 2)
*7
R/W
20.00 -999.99 to +999.99
6C
LOW setting value (Bank 2)
*7
R/W
10.00 -999.99 to +999.99
6D
Shift target value (Bank 2)
*7
R/W
0.00 -999.99 to +999.99
6E
HIGH setting value (Bank 3)
*7
R/W
20.00 -999.99 to +999.99
6F
LOW setting value (Bank 3)
*7
R/W
10.00 -999.99 to +999.99
70
Shift target value (Bank 3)
*7
R/W
0.00 -999.99 to +999.99
71 to
83
Reserved
InstID
(DEC)
AttrID
(HEX)
Name
Description Attribute
Default
value
Parameter range
