3-2 I/O Communication
3-14 - DeviceNet Compatible Network Unit DL-DN1 User's Manual -
3
Comm
un
ica
ti
ng wit
h th
e
IB
Ser
ies
IN area
n: The first device number assigned to the DL-DN1
The device assignments are the same for all 3-output modes including extended
modes.
„5-output mode
OUT area
n: The first device number assigned to the DL-DN1
Device
(DEC)
Name
Bit 7 Bit 6 ... Bit 1 Bit 0
Bit 15 Bit 14 ... Bit 9 Bit 8
n㪂㪎 Setting-value rewrite error
ID08 ID07 ... ID02 ID01
Reserved ID15 ... ID10 ID09
n㪂㪏
HIGH setting value (BANK 0)
rewrite complete
ID08 ID07 ... ID02 ID01
Reserved ID15 ... ID10 ID09
n㪂㪐
LOW setting value (BANK 0)
rewrite complete
ID08 ID07 ... ID02 ID01
Reserved ID15 ... ID10 ID09
n㪂㪈㪇
Shift target value (BANK 0)
rewrite complete
ID08 ID07 ... ID02 ID01
Reserved ID15 ... ID10 ID09
Device
(DEC)
Name
Bit 7 Bit 6 ... Bit 1 Bit 0
Bit 15 Bit 14 ... Bit 9 Bit 8
n㪂㪌
Request to rewrite HIGH
setting value (BANK 0)
ID08 ID07 ... ID02 ID01
Reserved ID15 ... ID10 ID09
n㪂㪍 HIGH setting value (BANK 0)
HIGH setting value to be rewritten
(4-byte signed integer)
n㪂㪏
Request to rewrite LOW
setting value (BANK 0)
ID08 ID07 ... ID02 ID01
Reserved ID15 ... ID10 ID09
n㪂㪐 LOW setting value (BANK 0)
LOW setting value to be rewritten
(4-byte signed integer)
n㪂㪈㪈
Request to rewrite shift
target value (BANK 0)
ID08 ID07 ... ID02 ID01
Reserved ID15 ... ID10 ID09
n㪂㪈㪉 Shift target value (BANK 0)
Shift target value to be rewritten
(4-byte signed integer)
n㪂㪈㪋
Request to rewrite HIGH
setting value (BANK 1)
ID08 ID07 ... ID02 ID01
Reserved ID15 ... ID10 ID09
n㪂㪈㪌 HIGH setting value (BANK 1)
HIGH setting value to be rewritten
(4-byte signed integer)
n㪂㪈㪎
Request to rewrite LOW
setting value (BANK 1)
ID08 ID07 ... ID02 ID01
Reserved ID15 ... ID10 ID09
n㪂㪈㪏 LOW setting value (BANK 1)
LOW setting value to be rewritten
(4-byte signed integer)
