3-2 I/O Communication
3-6 - DeviceNet Compatible Network Unit DL-DN1 User's Manual -
3
Comm
un
ica
ti
ng wit
h th
e
IB
Ser
ies
"3-output + current value" mode
5-output mode
"5-output + current value" mode
3-output + monitor
No extended mode Yes - - -
3-input - Yes Yes Yes
BANK change - - Yes -
Setting value rewrite - - - Yes
Area IN OUT IN OUT IN OUT IN OUT
Number of sensor
amplifiers
1 14
0
20
6
24
10
28
24
2 18 24 28 32
3 22 28 32 36
4 26 32 36 40
(bytes)
5-output
No extended mode Yes - - -
5-input - Yes Yes Yes
BANK change - - Yes -
Setting value rewrite - - - Yes
Area IN OUT IN OUT IN OUT IN OUT
Number of sensor amplifiers 1-4 12 0 22 10 26 14 34 40
(bytes)
5-output + current
value
No extended mode Yes - - -
5-input - Yes Yes Yes
BANK change - - Yes -
Setting value rewrite - - - Yes
Area IN OUT IN OUT IN OUT IN OUT
Number of sensor
amplifiers
1 18
0
28
10
32
14
40
40
2 22 32 36 44
3 26 36 40 48
4 30 40 44 52
(bytes)
