3-3 Explicit Messaging
3-34 - DeviceNet Compatible Network Unit DL-DN1 User's Manual -
3
Comm
un
ica
ti
ng wit
h th
e
IB
Ser
ies
Nx10+4
78 External input 3 function selection *18 R/W 0
0: Timing input
1: Bank A input
2: Bank B input
3: Laser emission stop input
4: Not use
79 External input 4 function selection *18 R/W 4
0: Adjust input
1: Bank A input
2: Bank B input
3: Laser emission stop input
4: Not use
7A Bank switching method R/W 0
0: Button
1: External input
7B Reserved
7C Save zero-shift state R/W 0
0: OFF
1: ON
7D Reserved
7E Display digit R/W 0
0: Default
01: 00.0
02: 00.0
03: 00.0
04: 00.1
5: 01
7F Power save function R/W 0
0: OFF
1: Half
2: All
080 Reserved
81 Judgment indicator color R/W 0
0: Green for GO only (Default)
1: Red for GO only
2: All green
3: All red
82 P. V. value display color R/W 0
0: Green for GO (Default)
1: Red for GO
2: All green
3: All red
83 Reserved
Nx10+5
64 Group-5 entry count R 9
65 Save adjust state R/W 0
0: OFF
1: ON
66 Adjust level R/W 20 1 to 30
67 Auto adjust function R/W 0
0: Disabled
1: Enabled
68 Auto adjust level R/W 3.00 0.50 to 20.00
69 Check output function R/W 0
0: Disabled
1: Enabled
6A Check output light level R/W 10 1 to 30
6B Error output mode R/W 0
0: Normal mode (Default)
1: LX2 compatible mode
6C Hysteresis for trigger level R/W 0
0: Default
1: User setting
6D Hysteresis set value for trigger level *16 R/W 1.00 0.00 to 999.99
6E to
83
Reserved
InstID
(DEC) AttrID
(HEX)
Name Description Attribute
Default
value
Parameter range
