3-3 Explicit Messaging
3-29
- DeviceNet Compatible Network Unit DL-DN1 User's Manual -
3
Comm
un
ica
ti
ng wit
h th
e
IB
Ser
ies
*1
Correction will not be possible if a setting change occurs between the target 1
and target 2 execution requests. When corrections are being performed, do not
change the settings during the processing.
Note also, that the "auto adjust" function is disabled between the target 1 and
target 2 execution requests. Be sure to follow the target 1 execution request
with a target 2 execution request.
N
6F
Adjust request
C
Executes the adjustment function. Turning off the power to the
sensor amplifier after executing the adjustment function restores
the same state as before executing adjustment function. If to
retain the adjusted value after turning off the power, turn on the
save adjust state hold function.
70
Adjust reset request
C
Initializes the adjustment value.
71
Reserved
72
Tolerance tuning request
C
Executes tolerance tuning
The setting width of tolerance is set in the setting/status com-
mand parameter "tolerance tuning setting width."
73
2-point tuning HIGH side 1st
request
C
Executes 2-point tuning.
For the operating procedure, refer to the IB Series User's Man-
ual.
74
2-point tuning HIGH side 2nd
request
C
75
2-point tuning LOW side 1st
request
C
76
2-point tuning LOW side 2nd
request
C
77
Measured correction 1st
request
*1
C
Executes measured correction.
The R. V. value to be displayed is set using the setting/status
command parameters "Measured/Logical correction target 1"
and "Measured/Logical correction target 2."
For the operating procedure, refer to the IB Series User's Man-
ual.
78
Measured correction 2nd
request
*1
C
79 to
7D
Reserved
7E
Logical correction 1st
request
*1
C
Executes logical correction.
The R.V. value to be calibrated is set in the setting/status com-
mand parameters "Logical correction measured 1" and "Logical
correction measured 2."
The R. V. value to be displayed is set using the setting/status
command parameters "Measured/Logical correction target 1"
and "Measured/Logical correction target 2."
For the operating procedure, refer to the IB Series User's Man-
ual.
7F
Logical correction 2nd
request
*1
C
80 to
83
Reserved
InstID
(DEC)
AttrID
(HEX)
Name
Description
Attribute
