3-2 I/O Communication

3-13

- DeviceNet Compatible Network Unit DL-DN1 User's Manual -

3

Comm

un
ica
ti

ng wit

h th

e

IB

Ser

ies

„5-output mode

OUT area

m: The first device number assigned to the DL-DN1

IN area

n: The first device number assigned to the DL-DN1
The device assignments are the same for all 5-output modes including extended
modes.

Rewrite setting value

Sensor amplifier ID numbers 01 to 04 are assigned to bits 0 to 3, respectively.

For details of communication methods, see

"Rewriting a setting value of a sensor

amplifier" (page 3-19).

„3-output mode

OUT area

n: The first device number assigned to the DL-DN1

Device

(DEC)

Name

Bit 7

Bit 6

...

Bit 1

Bit 0

Bit 15

Bit 14

...

Bit 9

Bit 8

m+5

Request to change BANK

ID08

ID07

...

ID02

ID01

Reserved

ID15

...

ID10

ID09

m+6

Select BANK number

Specifies a new BANK number

(2-byte unsigned integer; range: 0-3).

Device

(DEC)

Name

Bit 7

Bit 6

...

Bit 1

Bit 0

Bit 15

Bit 14

...

Bit 9

Bit 8

n+11

BANK change complete

ID08

ID07

...

ID02

ID01

Reserved

ID15

...

ID10

ID09

n+12

BANK change error

ID08

ID07

...

ID02

ID01

Reserved

ID15

...

ID10

ID09

Device

(DEC)

Name

Bit 7

Bit 6

...

Bit 1

Bit 0

Bit 15

Bit 14

...

Bit 9

Bit 8

n㪂㪊

Request to rewrite HIGH

setting value (BANK 0)

ID08

ID07

...

ID02

ID01

Reserved

ID15

...

ID10

ID09

n㪂㪋

HIGH setting value (BANK 0)

HIGH setting value to be rewritten

(4-byte signed integer)

n㪂㪍

Request to rewrite LOW

setting value (BANK 0)

ID08

ID07

...

ID02

ID01

Reserved

ID15

...

ID10

ID09

n㪂㪎

LOW setting value (BANK 0)

LOW setting value to be rewritten

(4-byte signed integer)

n㪂㪐

Request to rewrite shift

target value (BANK 0)

ID08

ID07

...

ID02

ID01

Reserved

ID15

...

ID10

ID09

n㪂㪈㪇

Shift target value (BANK 0)

Shift target value to be rewritten

(4-byte signed integer)
