Configuring the Sample Data Export analysis
1. Select
Analyses
from the VISCPRO
®
menu options.
2. Select
View Analysis
from the Analyses menu options
3. Double-click
Data Export Package
from the list of available
analysis types.
4. Select the
Sample Data Export
analysis option.
5. Click the
Define and Open New Configuration
radio button
to
define a new analysis configuration.
NOTE
If you have already configured and saved an analysis, its name will appear
in the list box on the right side of the window. If you click on an existing
configuration and click OK, the analysis will be performed using the
selected configuration settings. It will not be necessary to complete the
remaining steps in this procedure.
6. Click
OK
. The
ASCII Ports Output Configuration
window will
appear.
The
ASCII Ports Output Configuration
window consists of three
tabbed pages:
Date Filter
—allows you to select date/time parameters for the
analysis.
Sample Filter
—allows you to select which tubes/technicians/tests
will be included in the analysis.
Port Output Format
—allows you to select the output port(s), what
sample data will appear in the output analyses, and how the data will
be displayed/sent.
7. Click on the tab corresponding to the filter you wish to set and
complete configuration options per the following instructions:
Date/Sample filters
a. Complete selection of Date and Sample filter options per the
instructions in Chapter 6.
Port Output Format filter
b. To select other analysis configuration options, click the
Port
Output Format
tab.
Adding ports
c. Click
Add Port
from the
Port Output Format
button options to
open the
Select Port
window. Select the desired serial port(s) and/
or files for output and verify the configuration settings for each.
Then Click
OK
. Added ports will be displayed in the port list box.
