5. Click on the Define and Open New Configuration radio button
(or verify that the option is selected).
NOTE If you have already configured and saved an analysis, its name will appear
in the list box on the right side of the window. If you click on an existing
configuration and click OK, the analysis will be performed using the
selected configuration settings. It will not be necessary to complete the
remaining steps in this procedure.
6. Click OK . The Sample Analysis Configuration window will
appear.
The
Sample Analysis Configuration window consists of three
tabbed pages:
Date Filter —allows you to select date/time parameters for the
analysis
Sample Filter —allows you to select which tubes/technicians/tests
will be included in the analysis.
Report —allows you to select what sample data will appear in the
CAV Data Table and how the data will be displayed
7. Click on the tab corresponding to the filter you wish to set and
complete configuration options per the instructions below:
Date/Sample filters
Complete selection of Date/Sample filter options per the instructions
in Chapter 6.
Report filter To select data for inclusion in the Analysis, click the Report tab.
Then select which fields to include in the report by clicking the “ Click
here... ” box and selecting the desired data from the drop-down list.
After individual options have been selected, review the default
settings for
Precision , Format and Units [of measure] . You may
change the default values by double-clicking the box with the default
value. A drop-down menu will appear, providing other optional values.
Select the desired replacement value by clicking on it (or type an
acceptable value and then press the
R key).
