42 DISTO™ pro 4 / pro 4 a-1.0.0en English
en
The second measured value appears
beside the corresponding number
"2".
At the same time the next height to
be measured (roof ridge) is marked
in black with the corresponding
number "3".
Press briefly to change into
Pointing mode.
Aim the laser at the first bottom side.
Trigger measurement. Hold
DISTO steady.
Pressing and holding trigger key in
Pointing mode starts maximum
tracking.
Briefly press trigger key again when
measurement is done.
Press briefly to confirm
displayed value.
Each of the three displayed
measured values can be
selected with the navigation key
again and corrected by a new
measurement.
Calculation, contd.
After confirmimg the last
measurement, press briefly to
start computation.
gable area 5.5
1
2
3
0 3.547m
0 9.812m
0 9.812m
The first height to be measured (rain
gutter height) and the corresponding
number "1" are marked in black
Press briefly to change into
Pointing mode.
Aim laser at the first point to be
measured.
Trigger measurement. Hold
DISTO steady.
If there is the possibility of a
shaky measurement in the
Pointing mode either:
- use the time delay release (x-key)
- or press the trigger key long enough
to start tracking.
Press briefly to confirm
displayed value.
gable area 5.5
1
2
3
1
2
3
0 3.547m
0 3.547m
gable area 5.5
The first measured value appears
beside the corresponding number
"1". At the same time the next gable
width to be measured is marked in
black with the corresponding number
"2".
Measure gable or house width as
described earlier and confirm with
Enter key.
Pressing and holding trigger key in
Pointing mode starts tracking.
Briefly press again to quit
menu and to display the
marked result in basic
settings.
If desired, save result to keypad or
data memory.
Circle (5.6)
This menu function computes the
area of a circle using the diameter.
1 53.789m 2
gable area 5.5
