18 DISTO™ pro 4 / pro 4 a-1.0.0en English
en
Using end covers, contd.
Or use the end cover with folded in
positioning bracket / alignment aid.
Measuring from corners
Exact measurements from corners
can only be made with the end cover
with swivel foot.
Just keep the swivel foot in its initial
position (aligned with the edge of the
end cover).
PD-Z30
Measuring from edge
Normally the end cover with the
positioning bracket / alignment aid is
used.
As an auxiliary stop, the opened
closing cap of the interface plug can
be used.
PD-Z34
The stand as measuring reference
must be entered, when using the
auxiliary stop.
Measuring with alignment aid
The DISTO is ideally suited for
"marking-off ops." - e.g. when staking
out distances.
PD-Z38 PD-Z12
Measuring with stand
Using a stand eliminates shaking
when measuring over a long
distance.
The stand connection on the bottom
of the casing of the DISTO is
normally used.
The thread of the stand
should not be longer than 5.5
mm or it could damage the casing of
the DISTO.
PD-Z82
PD-Z83
