19 DISTO™ pro 4 / pro 4 a-1.0.0en English
en
Using end covers, contd.
Measuring with accessories
The adapter end cover has two
threads for attachments (e.g.
customer specified end covers).
PD-Z31
Optional measurement attachments:
• Short bracket (723775)
• Long bracket (723776)
Read user information under
"Accessories".
The DISTO has special menu
functions (2.2.2 and 2.2.3), to set
measuring references with these
optional devices.
PD-Z51
M4 (2x
)
46 m
m
A 1/4
To use the DISTO in high and
hard to reach places, attach
the extendable telescopic rod to the
stand's connection.
Sequential measurements can be
linked using mathematical functions
or input values.
Corrective measures
A brief press deletes/repeats
the last entry, an intemediate
result or a faulty measured
value.
Corrections are only possible
if the Result / Enter key has
not been pressed.
Length
Total height, total distance
Measurement + measurement = sum
Measurement
Addition
Measurement
= Sum
Simple Calculations
In the same way chain
measurements (any amount
of distance measurements) and
sums of areas / volumes can be
added up.
Partial heights, partial distances
Measurements - measurements =
difference
Measurement
Subtraction
Measurement
= Difference
Doubling a measured value
It is easy to double the measured
value to obtain, e.g. the
circumference of a room:
Measurement
Addition
Measurement
= Sum
(half circumference)
