24 DISTO™ pro 4 / pro 4 a-1.0.0en English
en
Measurement settings, contd.
Tracking (1.5)
Tracking for the DISTO is selectable
in this submenu.
This function permits moving objects
to be measured and stake outs
placed to a fixed object.
Default setting: off (1.5.2)
On (1.5.1)
After pressing the Enter key, a short
confirmation appears and the menu
function is terminated.
DISTO changes to Normal mode and
displays the basic settings with
"Track" appearing in the uppermost
line.
Tracking is started by pressing the
trigger key twice.
The lowest line displays the
continuously updated measured
value.
A brief press on the trigger key ends
tracking. The most recent measured
value can now be saved or used in a
computation.
Frequent and long tracking
uses up battery power very
rapidly.
Off (1.5.2)
After pressing the Enter key, a short
confirmation appears and the menu
function is terminated.
The DISTO changes to Normal mode
and displays the basic settings.
Data transfer (1.6)
This submenu permits immediate
data tranfer from the DISTO via the
data interface to a PC or a laptop.
End covers (2)
, 1x
Without end cover (2.1)
This menu function permits the use
of the DISTO without end cover.
After pressing the Enter key a short
confirmation appears and the menu
function is terminated.
Default settig: off (1.6.3)
On (1.6.1)
All measurements and calculations
are transferred; the data interface
transfers data continuously.
Only results (1.6.2)
Only measurement or calculation
results (e.g. at maximum or minimum
tracking) are transferred.
Off (1.6.3)
The data interface is off.
These menu functions are
described in the Online-
documentation on the CD-ROM
supplied.
tracking 1.5
1 on
2 off
send 1.6
1 on
2 only results
3 off
menu
1 measure settings
2 end cover
3 basic settings
4 basic functions
5 calculation
6 memory
end cover 2
1 without end cover
2 adapter end cover
3 recognition
