Routing
The router supports both static routing for manual routing table entry
addition, and dynamic routing for automatic routing table update.
The following diagram illustrates a wireless LAN having subnet
192.168.168.0 in which a router (
X
) with IP address 192.168.168.1
functions as Internet access point while a router (
Y
) with IP address
195.165.150.2 connects to a remote office, of subnet 195.165.150.0.
In this scenario, if client A wants to communicate with the remote client
D, when the router (
X
) sees the packets with the destination IP address
of D, it will search for and send the routing table information to the
router (
Y
) to route the packets to the specified destination.
!
NOTE: The default settings of the router allow broadband
Internet sharing so there is no need to configure any further
routing information.
Improper routing settings might cause improper functioning.
X
Y
