36
How to Setup WPA Enterprise Modes
Follow these steps to setup the router to use WPA Enterprise, WPA2
Enterprise, and WPA Auto Enterprise.
WPA Enterprise
1. Select the Cipher Type to
implement:
•
TKIP
• AES
• AUTO
The Cipher Type is set to
AUTO by default so that the
router can automatically
detect which cipher type
can be supported by the
client.
2. Key in the IP address of the
RADIUS Server in your WLAN.
Note: The RADIUS server MUST be
in the same subnet as your
router.
3. The Authentication Port is
preset as 1812, but another
port number can be used.
Note: The Authentication Port
MUST match the corresponding
port of the RADIUS server.
4. Enter the Shared Secret Key ,
known only to you and the
RADIUS server.
5. The Accounting Port is preset
as 1813 , but another port
number can be used.
1
6. Click Apply .
7. Click
on Reboot to restart
the system, after which your
settings will become
effective.
