81
The Port Forward Entries table displays
the list of current port-based entries.
Click Add .
2
For standard server applications
(HTTP/FTP/POP3/Netmeeting), go
to
Known Server :
1. Enter the Private IP
Address .
2. Pick the appropriate
Server Type .
3. Enter the range in the
From: and To: fields.
4. Click Add .
3
We entered a Private IP Address of
192.168.168.55 , defined ports 15 to 89 as
the application Ports, selected UDP from
the Protocol drop-down list and labeled
the Server Type as
LAN Game .
To set up Internet applications not
included under
Known Server , go
to Custom Server :
1. Enter the Private IP
Address .
2. Define the Port numbers
to use.
3. Select the relevant
Protocol from the drop
down list.
4. Identify the Server Type .
5. Enter the From: and To:
fields.
6. Click on Add .
