Compex Technologies NetPassage 18A - Manual (Page 18)

9
Panel Description
Name Description
Steady
Green The device is powered up.
1 Power (LED)
Off No power is supplied to the
device.
Steady
Green The WAN connection is ON.
2 WAN (Link/Activity LED)
Flashing
Green Data transmission at WAN
connection.
Steady
Green
Wireless interface up and
running.
Ready for operation.
3 WLAN (1), (2)
(Link/Activity LED)
Flashing
Green Activity is detected in the wireless
network.
These LEDs reflect the status of the integrated
Fast Ethernet Switch.
They will light up when connected with an
Ethernet cable.
Steady
Green
There is a connectivity link of
100Mbps.
Flashing
Green 100Mbps data transmission is
detected at the port
concerned.
Steady
Amber
There is a connectivity link of
10Mbps.
4 1, 2, 3, 4
(Link/Activity/Speed
LEDs)
Flashing
Amber 10Mbps data transmission is
detected at the port
concerned.
5 DIAG (LED) This LED is reserved for diagnostic purposes.
