Compex Technologies NetPassage 18A - Manual (Page 93)

84
IP Forwarding
If you have subscribed to more than one IP address from your ISP, you
may define Virtual Servers based on their IP address so that incoming
Internet requests are forwarded to specific computers within the private
network.
Assuming you subscribe to the range of Public IP addresses 203.120.12.1
to 203.120.12.62 from your ISP and the PC hosting a server has a LAN IP
address of 192.168.168.100:
To define the Internet Server as having an IP address of 203.120.12.62,
you can set a NAT Static IP Address Entry such that Internet requests to
203.120.12.62 are forwarded to 192.168.168.100 regardless of the
TCP/UDP port.
Follow these steps to setup an IP-Forwarding Virtual Server.
IP Forwarding
1. Click NAT from the
CONFIGURATION menu.
2. Ensure NAT Status is set
to enable.
3. At Advanced NAT
Options:
Click
IP Forwarding .
1
The NAT Static IP Address Entries table
displays the list of current port-based
entries.
Click Add .
2
