STP Setup
Spanning Tree Protocol is a link management protocol that provides path
redundancy while preventing undesirable loops in the network. For an Ethernet
network to function properly, only one active path can exist between two
stations.
Multiple active paths between stations cause loops in the network. If a loop
exists in the network topology, the potential exists for duplication of messages.
When loops occur, some switches see stations appear on both sides of the
switch. This condition confuses the forwarding algorithm and results in duplicate
frames being forwarded.
Enabling Spanning Tree Protocol
Click STP Setup from the CONFIGURATION
menu.
Select Enable, and click Apply to allow
spanning tree protocol to be activated
on the router.
STP Status:
Spanning Tree Protocol (STP)
function makes your network more
resilient to link failure and avoids
loop formation.
