Compex Technologies NetPassage 18A - Manual (Page 44)

35
How to Setup 802.1x
802.1x
1. Key in the IP address of
the Primary RADIUS Server in
your WLAN.
Optional: You may also key in a
Secondary RADIUS Server, if
any.
Note: The RADIUS server MUST be
in the same subnet as your router.
2. The
Authentication Port is
preset as 1812, but another port
number can be used.
Note: The Authentication Port
MUST match the corresponding
port of the RADIUS server.
3. Enter
the Shared Secret
Key , known only to you and the
RADIUS server.
4. The
Accounting Port is
preset as 1813 , but another port
number can be used.
5.
You can opt for a Key
Length of either 64 bits (10 hex /
5 ASCII values) or 128 bits (26
hex / 13 ASCII values).
6. Click
on Apply .
7. Click
on Reboot to restart
the system, after which the
settings will be effective.
1
