2–38 Internal Architecture Alpha 21264/EV67 Hardware Reference Manual
AMASK and IMPLVER Instruction Values
2.15 AMASK and IMPLVER Instruction Values
The AMASK and IMPLVER instructions return processor type and supported architec-
ture extensions, respectively.
2.15.1 AMASK
The 21264/EV67 returns the AMASK instruction values provided in Table 2–15. The
I_CTL register reports the 21264/EV67 pass level (see I_CTL[CHIP_ID], Section
5.2.15).
The AMASK bit definitions provided in Table 2–15 are defined in Table 2–16.
2.15.2 IMPLVER
For the 21264/EV67, the IMPLVER instruction returns the value 2.
DNZ [48] RW Denormal operands to zero. If this bit is set, treat all Denormal operands as a
signed zero value with the same sign as the Denormal operand.
Reserved [47:0]
1
— —
1
Alpha architecture FPCR bit 47 (DNOD) is not implemented by the 21264/EV67.
Table 2–15 21264/EV67 AMASK Values
21264/EV67 Pass Level AMASK Feature Mask Value
See I_CTL[CHIP_ID], Table 5–11 307
16
Table 2–16 AMASK Bit Assignments
Bit Meaning
0 Support for the byte/word extension (BWX)
The instructions that comprise the BWX extension are LDBU, LDWU, SEXTB,
SEXTW, STB, and STW.
1 Support for the square-root and floating-point convert extension (FIX)
The instructions that comprise the FIX extension are FTOIS, FTOIT, ITOFF, ITOFS,
ITOFT, SQRTF, SQRTG, SQRTS, and SQRTT.
2 Support for the count extension (CIX)
The instructions that comprise the CIX extension are CTLZ, CTPOP, and CTTZ.
8 Support for the multimedia extension (MVI)
The instructions that comprise the MVI extension are MAXSB8, MAXSW4,
MAXUB8, MAXUW4, MINSB8, MINSW4, MINUB8, MINUW4, PERR, PKLB,
PKWB, UNPKBL, and UNPKBW.
9 Support for precise arithmetic trap reporting in hardware. The trap PC is the same as
the instruction PC after the trapping instruction is executed.
Table 2–14 Floating-Point Control Register Fields (Continued)
Name Extent Type Description
