Alpha 21264/EV67 Hardware Reference Manual

Electrical Data

9–7

AC Characteristics

The input voltage swing is Vref ± 0.40 Volts.

All output skew data is based on simulation into a 50-ohm transmission line that is
terminated with 50 ohms to VDD/2 for Bcache timing, and with 50 ohms to VDD
for all other timing.

Timings are measured at the pins as follows:

For open-drain outputs, timing is measured to (V

ol

+ V

term

)/2. Where V

term

is

the offchip termination voltage for system signals.

For non-open-drain outputs, timing is measured to (V

ol

+ V

oh

)/2.

For all inputs other than type I_DA_CLK, timing is measured to the point
where the input signal crosses VREF.

For type I_DA_CLK inputs, timing is measured when the voltage on the com-
plementary inputs is equal.

Table 9–13 AC Specifications

Signal Name

Type

Reference Signal

TSU

1

TDH

2

TSkew

Duty Cycle

TSlew

SysAddIn_L[14:0

I_DA

SysAddInClk_L

400 ps

400 ps

NA

NA

1.0 V/ns

SysFillValid_L

I_DA

SysAddInClk_L

400 ps

400 ps

NA

NA

1.0 V/ns

SysDataInValid_L

I_DA

SysAddInClk_L

400 ps

400 ps

NA

NA

1.0 V/ns

SysDataOutValid_L

I_DA

SysAddInClk_L

400 ps

400 ps

NA

NA

1.0 V/ns

SysAddInClk_L

I_DA

NA

NA

NA

NA

45–55%

1.0 V/ns

SysAddOut_L[14:0]

O_OD

SysAddOutClk_L

NA

NA

± 300 ps

3

NA

NA

SysAddOutClk_L

O_OD

EV6Clk_x

NA

NA

± 400 ps

45-55%

NA

SysData_L[63:0]

B_DA_OD

SysDataInClk_H[7:0]

400 ps

400 ps

NA

NA

1.0 V/ns

SysDataOutClk_L[7:0]

4

NA

NA

± 300 ps

3

NA

NA

SysCheck_L[7:0]

B_DA_OD

SysDataInClk_H[7:0]

400 ps

400 ps

NA

NA

1.0 V/ns

SysDataOutClk_L[7:0]

4

NA

NA

± 300 ps

3

NA

NA

SysDataInClk_H[7:0]

I_DA

NA

NA

NA

NA

45-55%

1.0 V/ns

SysDataOutClk_L[7:0]

O_OD

EV6Clk_x

NA

NA

± 400 ps

45-55%

NA

BcAdd_H[23:4]

O_PP

BcTagOutClk_x

NA

NA

± 300 ps

5,6

NA

BcDataOE_L

O_PP

BcDataOutClk_x[3:0]

7

45-55%

BcLoad_L

O_PP

38-63%

8

BcDataWr_L

O_PP

40-60%

9

BcData_H[127:0]

B_DA_PP

BcDataOutClk_x[3:0]

10

NA

NA

± 300 ps

6

45-55%

1.0 V/ns

38-63%

8

NA

40-60%

9

NA

BcDataInClk_H[7:0]

400 ps

400 ps

NA

NA

NA

BcDataInClk_H[7:0]

I_DA

NA

NA

NA

NA

45-55%

BcDataOutClk_H[3:0]

O_PP

EV6Clk_x

NA

NA

± 400 ps

BcDataOutClk_L[3:0]

O_PP

EV6Clk_x

NA

NA

± 400 ps

BcTag_H[42:20]

B_DA_PP

BcTagInClk_H

400 ps

400 ps

NA

NA

1.0 V/ns

BcTagDirty_H

B_DA_PP

BcTagInClk_H

400 ps

400 ps

NA

NA

1.0 V/ns

BcTagParity_H

B_DA_PP

BcTagInClk_H

400 ps

400 ps

NA

NA

1.0 V/ns
