7–4

Initialization and Configuration

Alpha 21264/EV67 Hardware Reference Manual

Power-Up Reset Flow and the Reset_L and DCOK_H Pins

In addition, as power is being ramped, Reset_L must be asserted — this allows the
21264/EV67 to reset internal state. Once the target voltage levels are attained, systems
should assert DCOK_H. This indicates to the 21264/EV67 that internal logic functions
can be evaluated correctly and that the power-up sequence should be continued. Prior to
DCOK_H being asserted, the logic internal to the 21264/EV67 is being reset and the
internal clock network is running (either clocked by the PLL VCO, which is at a nomi-
nal speed, or by ClkIn_H, if the PLL is bypassed).

The reset state machine is in state WAIT_SETTLE.

7.1.2 Clock Forwarding and System Clock Ratio Configuration

When DCOK_H is asserted, the 21264/EV67 samples several pins and latches in some
initialization state, including the value of the PLL Y

div

divisor, which specifies the

ratio of the system clock to the internal clock (see Section 7.11.2.3), and enables the
charge pump on the phase-locked loop.

SysAddOut_L[14:0]

Initially, during power-up reset, state
is not defined. If not during power-
up, preserves previous state. Then,
after the clock forward reset period
(as the external clocks start), signal
driven to NZNOP until the reset
state machine enters RUN, when it
is driven to NOP.

SysDataOutValid_L

NA (input)

SysAddOutClk_L

Tristated

SysFillValid_L

NA (input)

SysCheck_L[7:0]

Tristated

SysVref

NA
(I_DC_REF)

SysData_L[63:0]

Tristated

Clocks

ClkFwdRst_H

NA (input)

FrameClk_x

NA (input)

ClkIn_H
ClkIn_L

NA (input)

PLL_VDD

NA
(I_DC_REF)

EV6Clk_H
EV6Clk_L

NA (input)

Miscellaneous

DCOK_H

Must be deasserted until dc voltage
reaches proper operating level.

Tck_H

NA (input)

PllBypass_H

NA (input)

Tdi_H

NA (input)

Reset_L

NA (input)

Tdo_H

Unspecified

SromClk_H

Tristated

TestStat_H

Tristated

SromData_H

NA (input)

Tms_H

NA (input)

SromOE_L

Tristated

Trst_L

NA (input)

Table 7–2 Signal Pin Reset State (Continued)

Signal

Reset State

Signal

Reset State
