Index–4 Alpha 21264/EV67 Hardware Reference Manual
Dcache
described , 2–12
duplicate tag parity errors , 8–4
duplicate tags with , 4–13
error case summary for , 8–9
fill from Bcache error , 8–6
fill from memory errors , 8–7
initialized by BiST , 7–12
pipelined , 2–16
single-bit correctable ECC error , 8–3
store second error , 8–4
tag parity errors , 8–2
victim extracts , 8–4
Dcache data single-bit correctable ECC errors , 8–3
Dcache tag, initialized by BiST , 7–12
DCOK_H signal pin , 3–4
power-on reset flow , 7–1
DCVIC_THRESHOLD Cbox CSR, defined , 5–34
DFAULT fault , 6–13
Differential 21264/EV67 clocks , 7–19
Differential reference clocks , 7–19
Dirty cache block state , 4–10
Dirty/Shared cache block state , 4–10
Do not care convention , xxi
Double-bit fill errors , 8–9
DOWN1 reset machine state , 7–18
DOWN2 reset machine state , 7–19
DOWN3 reset machine state , 7–19
Dstream translation buffer , 2–13
See also DTB
DSTREAM_BC_DBL error status in C_STAT ,
5–41
DSTREAM_BC_ERR error status in C_STAT ,
5–41
DSTREAM_DC_ERR error status in C_STAT ,
5–41
DSTREAM_MEM_DBL error status in C_STAT ,
5–41
DSTREAM_MEM_ERR error status in C_STAT ,
5–41
DTAG. See Duplicate Dcache tag array
DTB entries, writing multiple in same PAL flow ,
D–19
DTB fill , 6–14
DTB, pipeline abort delay with , 2–16
DTB_ALTMODE alternate processor mode register ,
5–26
at power-on reset state , 7–15
DTB_ASN0 address space number register 0
at power-on reset state , 7–16
DTB_ASN0 address space number registers 0 , 5–28
DTB_ASN1 address space number register 1 , 5–28
at power-on reset state , 7–16
DTB_IA invalidate-all process register , 5–27
at power-on reset state , 7–15
DTB_IAP invalidate-all (ASM=0) process register ,
5–27
at power-on reset state , 7–15
DTB_IS0 invalidate single (array 0) register , 5–27
at power-on reset state , 7–16
DTB_IS1 invalidate single (array 1) register , 5–27
at power-on reset state , 7–16
DTB_PTE0 array write 0 register
at power-on reset state , 7–15
MTPR to , D–12
DTB_PTE0 array write register 0 , 5–26
DTB_PTE1 array write 1 register , 5–26
at power-on reset state , 7–15
MTPR to , D–12
DTB_TAG0 array write 0 register , 5–25
at power-on reset state , 7–15
MTPR to , D–12
DTB_TAG1 array write 1 register , 5–25
at power-on reset state , 7–15
MTPR to , D–12
DTBM_DOUBLE_3 fault , 6–13
DTBM_DOUBLE_4 fault , 6–13
DTBM_SINGLE fault , 6–13
Dual-data rate SSRAM pin assignments , E–3
DUP_TAG_ENABLE Cbox CSR, defined , 5–34
Duplicate Dcache tag array , 2–11
Duplicate Dcache, initialized by BiST , 7–12
Duplicate tag array, Cbox copy. See CTAG
Duplicate tag stores, Bcache , 4–7
E
Ebox
cycle counter control register CC_CTL , 5–3
cycle counter register CC , 5–3
described , 2–8
executed in pipeline , 2–16
internal processor registers , 5–1
slotting , 2–18
subclusters , 2–18
virtual address control register VA_CTL , 5–4
virtual address format register VA_FORM , 5–5
virtual address register , 5–4
ECB instruction, external interface reference , 4–5
