Index–8 Alpha 21264/EV67 Hardware Reference Manual
MB, 21264/EV67 command , 4–13 , 4–21
MB_CNT Cbox CSR, operation , 2–32
MBDone, SysDc command , 4–13
Mbox
Dcache control register DC_CTL , 5–30
Dcache status register DC_STAT , 5–31
described , 2–12
Dstream translation buffer , 2–13
DTB address space number registers 0 and 1
DTB_ASNx , 5–28
DTB alternate processor mode register
DTB_ALTMODE , 5–26
DTB invalidate-all (ASM=0) process register
DTB_IAP , 5–27
DTB invalidate-all process register DTB_IA ,
5–27
DTB invalidate-single registers 0 and 1
DTB_ISx , 5–27
DTB PTE array write registers 0 and 1
DTB_PTEx , 5–26
DTB tag array write registers 0 and 1
DTB_TAGx , 5–25
internal processor registers , 5–2
load queue , 2–13
Mbox control register M_CTL , 5–29
memory management status register
MM_STAT , 5–28
miss address file , 2–13
order traps , 2–31
pipeline abort delay with order trap , 2–16
pipeline abort delays , 2–16
store queue , 2–13
MBOX_BC_PRB_STALL Cbox CSR, defined ,
5–35
MCHK interrupt , 6–14
Mechanical specifications , 3–17
Memory
error case summary for , 8–10
filling Dcache errors , 8–7
filling Icache errors , 8–7
Memory address space
load instructions with , 2–27
merging rules , 2–30
store instructions with , 2–29
Memory barrier instructions
translation to external interface , 4–5
Memory barriers , 2–32
Memory reference unit. See Mbox
MF_FPCR instruction , 6–12
Microarchitecture
summarized , 2–1
MiscVref signal pin , 3–5
Miss address file , 2–13
I/O address space loads , 2–28
memory address space loads , 2–28
memory address space stores , 2–29
MM_STAT memory management status register ,
5–28
at power-on reset state , 7–16
MT_FPCR instruction , 6–12
MT_FPCR synchronous trap , 6–14
N
NoConnect pin type , 3–3
Nonexistent memory
processing , 4–38
NOP, 21264/EV67 command , 4–21
Note convention , xxi
Numbering convention , xxi
NXM. See Nonexistent memory
NZNOP, 21264/EV67 command , 4–21
O
O_OD pin type , 3–3 , 9–2
values for , 9–4
O_OD_TP pin type , 3–3 , 9–2
values for , 9–4
O_PP pin type , 3–3 , 9–2
values for , 9–5
O_PP_CLK pin type , 3–3 , 9–2
values for , 9–5
OPCDEC fault , 6–13
Opcodes
IEEE floating-point , A–9
independent floating-point , A–11
reserved for Compaq , A–8
reserved for PALcode , A–9
summary of , A–12
VAX floating-point , A–11
Open-drain driver for test pins. See O_OD_TP
Open-drain output driver. See O_OD pin type
Operating temperature , 10–1
P
Packaging , 3–18
Paired instruction fetch order , 6–9
PAL_BASE register , 5–15
after fault reset , 7–8
after warm reset , 7–11
at power-on reset state , 7–15
through sleep mode , 7–10
