Alpha 21264/EV67 Hardware Reference Manual Internal Architecture 2–17
Instruction Issue Rules
2.3.1 Instruction Group Definitions
Table 2–2 lists the instruction class, the pipeline assignments, and the instructions
included in the class.
Table 2–2 Instruction Name, Pipeline, and Types
Class
Name
Pipeline Instruction Type
ild L0, L1 All integer load instructions
fld L0, L1 All floating-point load instructions
ist L0, L1 All integer store instructions
fst FST0, FST1, L0, L1 All floating-point store instructions
lda L0, L1, U0, U1 LDA, LDAH
mem_misc L1 WH64, ECB, WMB
rpcc L1 RPCC
rx L1 RS, RC
mxpr L0, L1
(depends on IPR) HW_MTPR, HW_MFPR
ibr U0, U1 Integer conditional branch instructions
jsr L0 BR, BSR, JMP, CALL, RET, COR, HW_RET,
CALL_PAL
iadd L0, U0, L1, U1 Instructions with opcode 10
16
, except CMPBGE
ilog L0, U0, L1, U1 AND, BIC, BIS, ORNOT, XOR, EQV, CMPBGE
ishf U0, U1 Instructions with opcode 12
16
cmov L0, U0, L1, U1 Integer CMOV — either cluster
imul U1 Integer multiply instructions
imisc U0 CTLZ, CTPOP, CTTZ, PERR, MINxxx, MAXxxx, PKxx,
UNPKxx
fbr FA Floating-point conditional branch instructions
fadd FA All floating-point operate instructions except multiply,
divide, square root, and conditional move instructions
fmul FM Floating-point multiply instruction
fcmov1 FA Floating-point CMOV—first half
fcmov2 FA Floating-point CMOV— second half
fdiv FA Floating-point divide instruction
fsqrt FA Floating-point square root instruction
nop None TRAP, EXCB, UNOP - LDQ_U R31, 0(Rx)
