R E L I A N C E - I G S S I N S T A L L A T I O N M A N U A L
IW-115
90° Outside Corner
Face Cap
7 1/4" & 6" (2 Per Corner)
IW-241
IW-116
IW-240
135° Outside Corner
Face Cap
7 1/4" & 6" (2 Per Corner)
90° Corner Mullion
7 1/2" & 6 1/4"
1/4" Adaptor
90° and 135° corners
7 1/4" & 6"
WW-145
CORNER MULLIONS
& ACCESSORIES
WW-227
O.S. 90° Corner Mullion
Snap-In Back Trim
6 1/4"
IW-194-01
WW-105-04
WW-105-03
Splice Sleeve
for WW-240
"T" Anchor
for IW-243
"T" Anchor
for IW-241
"T" Anchor
for IW-240
Splice Sleeve
for WW-243
Splice Sleeve
for WW-241
90° Outside
Mullion Cap
135° Outside
Mullion Cap
IW-320
IW-321
IW-322
Zone Plug
135° Captured O.S.
CORNER MULLIONS
& ACCESSORIES - cont'd
Outside 90
Corner Mull
Reinforcement
IW-198
IW-199
Outside 135
7 1/2" Corner Mull
Reinforcement
Outside 135
6 1/4" Corner Mull
Reinforcement
IW-189
OS90° Right Hand
Shear Block
for IW-542
IW-242-01
CORNER MULLIONS
& ACCESSORIES - cont'd
IW-242-02
OS90° Left Hand
Shear Block
for IW-542
OS90° Right Hand
Shear Block
for IW-442
IW-244-01
IW-244-02
OS90° Left Hand
Shear Block
for IW-442
OS90° Right Hand
Shear Block
for IW-546 & IW-550
IW-245-01
IW-245-02
OS90° Left Hand
Shear Block
for IW-546 & IW-550
OS90° Right Hand
Shear Block
for IW-446 & IW-450
IW-246-01
IW-246-02
OS90° Left Hand
Shear Block
for IW-446 & IW-450
OS90° Right Hand
Shear Block
for IW-547
IW-247-01
IW-247-02
OS90° Left Hand
Shear Block
for IW-547
OS90° Right Hand
Shear Block
for IW-448
IW-248-01
IW-248-02
OS90° Left Hand
Shear Block
for IW-448
IW-243
135° Corner Mullion
7 1/2"
135° Corner Mullion
6 1/4"
WW-228
O.S. 90° Corner Mullion
Snap-In Back Trim
7 1/2"
IW-195-01
IW-185-01
WW-105-05
IS90
Corner Closure
IW-250
IW-251
Inside Corner
Closure Isolator
PARTS LIST
