Oldcastle BuildingEnvelope Reliance-IG SS - Manual (Page 55)

52 



R E L I A N C E - I G S S I N S T A L L A T I O N M A N U A L
WW-103-06
WW-103-05
STANDARD ACCESSORIES
All System Depths and Infills
"T" Anchor
for IW-440 & IW-444
Zone Plug
Typical Mullion
& 90° O.S. Captured
"T" Anchor
for IW-540 & IW-544
WW-174-06
WW-174-05
ICR-107-01
SSG Mull Bridge
for Outside Glazed
Horizontals
WW-300
Vertical Mullion Splice
for IW-541 & IW-545
Vertical Mullion Splice
for IW-540 & IW-544
IW-190-01
GP-110
GP-109
1/4" Setting Block
(2 Per Lite)
1" Setting Block
(2 Per Lite)
Setting Chair
for Sill
IW-121
Weep Baffle
Sill Member
HP-1004
"F" Anchor
for IW-543
Jamb Mullion
Captured & SSG
Mullion Cap
(Intermediates Only)
IW-325
Jamb Mullion Splice
for IW-543
IW-192-01
STANDARD ACCESSORIES
All System Depths and Infills
FS-325
#12-14 x 1 1/2" Hex Washer
Head Drillflex
Fastens Pressure Plate to
Mullion (WW-442 & WW-542)
#10 x 1/2" U-Drive
Fastens Mull Caps
FS-320
#14 x 1" Phillips Hex Head
Horizontals to Verticals &
Splice Sleeves to Mullions
FS-8
STANDARD FASTENERS
#10 x 1/2" Phillips
Round Head
Attach Reglaze Legs
FS-55
#10 x 1 3/8" Phillips Flat
Head SSG Mullion Adaptor
FS-119
FS-322
GP-101
1" Setting Block
(2 Per Lite)
Outside Glazed Horizontal
"F" Anchor
for IW-443
Jamb Mullion
Vertical Mullion Splice
for IW-441 & IW-445
Vertical Mullion Splice
for IW-440 & IW-444
IW-180-01
IW-181-01
Jamb Mullion Splice
for IW-443
IW-182-01
IW-191-01
Isolator Clips
@ 12" O,C,
ICW-12
Baffle Clips
@ Weep Holes
Horizontals
GP-141
Head Anchor Sleeve
IW-440 & IW-444
IW-183-01
#14 x 1-1/2" Phillips Hex
Head - Horizontals to
Verticals at Head Anchors
FS-9
#12-14 x 1" Hex Washer
Head Drillflex
Fastens Pressure Plate to
Mullion (WW-442 & WW-542)
& Attach Splices
FS-325
FSN-37
FSW-65
1/4"-20 x 1" Hex Head Bolt
for Steel Reinforcement
Attachment
1/4"-20 Hex Nut
1/4" Lock Washer
SSG Mull Bridge
for Head
IW-300-01
SSG Mull Bridge
for Horizontal
IW-301-01
Captured & SSG
Jamb Mullion Cap
IW-326
GP-102
SSG Spacer Gasket
Corner Mullions
1/4" F.C.
Thermal Isolator
GP-107
Temporary
Glazing Retainer
for SSG Verticals
Temporary
Glazing Retainer
for Captured Mullions
SPW-PP-3
WW-333-01
SSG Mull Bridge
for Sill
IW-302-01
Standard SunShade
Anchor
IW-107-01
Sealant block
for all typ. mullions
IW-122-01
Isolator Clip
Installation Tool
ICW-FP-74
STANDARD ACCESSORIES
All System Depths and Infills
Head Anchor Sleeve
IW-540 & IW-544
IW-193-01 GP-100
Reglaze Gasket
1/4" F.C.
PARTS LIST
