2
Kontron CG2200 Carrier Grade Server Installation and Maintenance Guide
Appendix B: Regulatory and Certification Information
presents the regulatory and safety compliances and electromagnetic compatibility notices
Appendix D: Getting Help
1.3 What Your Server Includes
Your CG2200 server includes the following components:
•
One 2U chassis
•
One Intel® Server Board S2600CO with DDR3 memory slots (memory not included)
•
Six removable hard drive carriers
•
One DC or AC power subsystem: one hot-swappable power supply module and a power
distribution board. (The other power supply bay has a filler panel in it. For redundancy
another separately orderable power supply module must be added.)
•
Six fan assemblies for cooling the processor(s), DIMM(s), PCI slot(s), and other internal
components in three cooling zones.
•
A front panel board ,LED/switch board, and telco alarms module (TAM) board
•
Internal cables and connectors
•
See Chapter 3 for initial installation and configuration instructions.
1.4 Product Accessories
The following list shows the separately orderable components and optional accessories available for
inclusion in the initial order or to have as spares. Refer to the CG2200 Carrier Grade Server Configuration
Guide for a complete list of orderable spares and options. The Configuration Guide can be found on the
Kontron Support Website at
http://us.kontron.com/support/ (search for CG2200, click on
Product Downloads, then Ordering Guide).
•
LGA 2011 (socket R) support for Intel® Xeon® E5-2600 and E5-2600 v2 processors family
•
Registered DDR3 Memory (RDIMM), LV-RDIMM, Unbuffered DDR3 Memory (UDIMM) with
ECC and Load Reduced DDR3 Memory (LR-DIMM)
•
Up to six hot-swappable 2.5” SAS HDDs or SATA SSDs
•
Hard disk drive carriers (six already shipped with the server)
•
Third-party LSI-based 6 Gbit SAS hardware RAID controller
•
Two front access SD media flash modules
•
Internal flash storage supported (eUSB and SATADOM)
•
Two risers (four FH/FL cards) and two LP adapters for a total of six PCIe Gen2/Gen3 I/O
cards
•
Power cord(s)
•
AC or DC power supply module (650W) for redundancy
•
Intel ® Remote Management Module 4 (RMM4) or RMM4Lite options
•
Rack mount kits
For information about the accessories, memory, processors, and ordering information, refer to the
CG2200 Carrier Grade Server Configuration Guide on
http://us.kontron.com/support/ (search
for CG2200, click on Product Downloads, then Ordering Guide).
For information about third-party hardware that has been tested and can be used with your system, refer
to the CG2200 Carrier Grade Server Tested Hardware and Operating System List (THOL) on
http://us.kontron.com/support/ (search for CG2200, click on Product Downloads, then
Compatibility Matrix).
