38
Kontron CG2200 Carrier Grade Server Installation and Maintenance Guide
Table 6. System Cables
Interconnect #: Name:
KAI Cable
P/N
End #1 Connection
End #2 Connection
End #3 Connection
End #4 Connection
1. Baseboard SSI Main Power
K00597-002
End #1: Power Distribution Board
End #2: Baseboard End #3: NA
End #4: NA
2. CPU 1 + DIMM Power
K00597-002
End #1:Power Distribution Board
End #2: Baseboard End #3: NA
End #4: NA
3. CPU 2 + DIMM Power
K00597-002
End #1:Power Distribution Board
End #2: Baseboard End #3: NA
End #4: NA
4. Fan Control Board Power
K00597-002
End #1:Power Distribution Board
End #2: Fan Control Board End #3: NA
End #4: NA
5. SAS HDD Backplane Board
Power
K00597-002
End #1:Power Distribution Board
End #2: SAS HDD Backplane End #3: NA
End #4: NA
6. Aux I/O Power Dongle
K00597-002
End #1:Power Distribution Board
End #2: Cable-to-cable connector End #3: NA
End #4: NA
7. Baseboard SSI Power
Control Signal
K00597-002
End #1:Power Distribution Board
End #2: Baseboard End #3: NA
End #4: NA
8. Multifunction Front Panel
Board (Pwr/Sig, HDD LED,
COM2)
K00539-001
End #1:Front Panel Board
(multifunction)
End #2: Fan Control Board
(pwr/sig)
End #3: Baseboard (COM2)
End #4: C-2-C (HDD-LED)
9. SSI Front Panel Board l
K00540-001
End #1: Baseboard
End #2: Front Panel Board End #3: NA
End #4: NA
10. Fan I2C
K00542-001
End #1: Baseboard
End #2: Fan Control Board End #3: NA
End #4: NA
11. Front Panel Board USB K00543-001
End #1: Baseboard
End #2: Front Panel Board End #3: NA
End #4: NA
12. LED/Switch Board Power
and Signal
E36035-001
End #1:Front Panel Board
End #2: LED/Switch Board End #3: NA
End #4: NA
13. TAM Signal K00544-001
End #1:Front Panel Board
End #2: TAM Module End #3: NA
End #4: NA
14. Alarms K00545-001
End #1:TAM Module
End #2: System Rear Panel Alarms
Connector
End #3: NA
End #4: NA
15. Fan
(Fans 1-2)
K00546-001
Used 3
End #1:Fan Control Board
End #2: Fan Pair (1-2) End #3: NA
End #4: NA
