Kontron CG2200 Carrier Grade Server Installation and Maintenance Guide
Table 10. POST Error Beep Codes
Beeps
Error Message
Post Progress Code
Description
1
USB device
action
N/A
Short beep sounded whenever a USB device is discovered
in POST or inserted or removed during runtime
1
Intel® TXT
security violation
0xAE, 0xAF
System halted because the Intel® Trusted Execution
Technology detected a potential violation of system
security
3
Memory error
Multiple
System halted because a fatal error related to the memory
was detected
The following Beep Codes are sounded during BIOS recovery
2
BIOS Recovery
started
N/A
Recovery boot has been initiated
4
BIOS Recovery
failure
N/A
BIOS recovery has failed. This typically happens so quickly
after recovery is initiated that it sounds like a 2 – 4 beep
code.
The Integrated BMC may generate beep codes upon detection of failure conditions. Beep codes are
sounded each time the problem is discovered, such as on each power-up attempt, but are not sounded
continuously. Codes that are common across all Intel server boards and systems that use the same
generation chipset are listed in the following table. Each digit in the code is represented by a sequence of
beeps whose count is equal to the digit.
Table 11. Integrated BMC Beep Codes
Beep
Code
Reason for Beep
Associated Sensors
1-5-2-1
CPU socket population error
CPU1 socket is empty or sockets are populated
incorrectly
CPU1 must be populated before CPU2
1-5-2-4
MSID mismatch
MSID mismatch occurs if a processor is installed into a
system board that has incompatible power capabilities
1-5-4-2
Power fault
DC power unexpectedly lost (power good dropout)
Power unit sensors report power unit failure offset
1-5-4-4
Power control fault
Power good assertion timeout
Power unit sensors report soft power control failure
offset
1-5-1-2
VR watchdog timer
VR controller DC power on sequence was not
completed in time
1-5-1-4
Power supply status
The system does not power on or unexpectedly powers
off and a Power Supply Unit (PSU) is present that is an
incompatible model with the other PSU in the system.
