Table 9. System Status LED Definitions
Color State Criticality Description
Green Solid on System OK System booted and ready
Green Blink Degraded
System degraded:
•
Non-critical temperature threshold asserted
•
Non-critical voltage threshold asserted
•
Non-critical fan threshold asserted
•
Fan redundancy lost, sufficient system
cooling maintained. This does not apply
to non-redundant systems.
•
Power supply predictive failure
•
Power supply redundancy lost. This does
not apply to non-redundant systems.
•
Corrective errors over a threshold of 10 and
migrating to a mirrored DIMM (memory
mirroring). This indicates the user no longer
has spare DIMMs indicating a redundancy
lost condition. The corresponding DIMM
LED should light up
Amber Blink Non-critical
Non-fatal alarm – system is likely to fail:
•
Critical temperature threshold asserted
•
CATERR asserted
•
Critical voltage threshold asserted
•
VRD not asserted
•
SMI timeout asserted
Amber Solid on
Critical, non-
recoverable
Fatal alarm – system has failed or shut down
•
CPU missing
•
Thermal Trip asserted
•
Non-recoverable temperature threshold
asserted
•
Non-recoverable voltage threshold
asserted
•
Power fault/power control failure
•
Fan redundancy lost, insufficient system
cooling. This does not apply to non-
redundant systems.
•
Power supply redundancy lost,
