Kontron CG2200 Carrier Grade Server Installation and Maintenance Guide
1. Power down the server and remove all peripheral devices and the power cord(s)
2. Remove the chassis cover. For instructions, see “Removing the Chassis Cover” in Section 3.2.
3. Remove the riser card assembly from the chassis. For instructions, see “Removing a Riser Card
Assembly” in Section 3.2.
4. Fasten the riser card to the bracket with the two 6/32 screws as shown in Figure 34
Torque screws to 8 lbf*in.
At this point the riser card is ready for you to install add-in cards.
4.7 Installing PCI Add-in Cards
The right-side and left-side riser card options support different combinations of PCIe and/or PCI-X add-in
cards. See Table 7 for the possible configurations. The figures in this section use the left-side slot 2 riser
card assembly, a PCI Express passive riser, dual slot x8 and full-height x8 add-in card options as the
example.
CAUTION: When handling a PCI add-in card, observe the normal safety and ESD precautions. See Appendix
A: Safety Information for more information.
To install a PCI add-in card, you must first remove the riser card assembly from the server chassis. See
“Removing a Riser Card Assembly” in Section 3.2 for more information.
1. Power down the server and remove all peripheral devices and the power cord(s)
2. Remove the chassis cover. For instructions, see “Removing the Chassis Cover”.
3. Remove the riser card assembly from the chassis. For instructions, see “Removing a Riser Card
Assembly”.
4. Turn the riser card assembly upside down so it is resting on the top of the sheet metal cage.
If you are replacing a PCI card in a slot, remove the rear retention screw that fastens the add-in card to
the riser card. (
5. Figure 35 “D”).
For a full-length card, also open the card edge retainer in the front of the assembly by loosening the
blue captive screw (“B”)
6. Remove the card from the riser card socket.
If you are adding a PCI card, not replacing one, in your selected slot, remove the blank filler panel from
the rear bracket of the riser card assembly. (
7. Figure 35, “A”)
8. For a full-length add-in card, open the card edge retainer by loosening the blue captive screw (“B”).
9. Attach the add-in card to the appropriate riser card connector. (“C”)
Be sure that the add-in card edge connector is seated in the riser card connector correctly.
10. Fasten the add-in card to the riser card assembly bracket using the rear retention screw. (“D”)
For full-length cards, also secure the card in the grooves at the slot level on the retainer bracket and
tighten the blue captive thumb screw. (“D”)
