26
Kontron CG2200 Carrier Grade Server Installation and Maintenance Guide
For detailed information about these different memory RAS modes, see Section 3.2.2.5, “Memory RAS” in
the Intel® Server Board S2600CO Family TPS.
3.3.6 Installing Memory DIMMs
NOTE: To reduce the risk of electrostatic discharge (ESD) damage to the processor or the DIMM, be sure to
follow these procedures:
1) Touch the metal chassis before touching the DIMM or server board.
2) Keep part of your body in contact with the metal chassis to dissipate the static charge while handling
the DIMM.
3) Avoid moving around unnecessarily.
4) Use a ground strap attached to the front panel (with the bezel removed).
To install DIMMs in the S2600CO server board slots, follow these steps:
1. Power down the server and remove all peripheral devices and the power cord(s)
2. Remove the chassis cover. For instructions, see “Removing the Chassis Cover” in Section 3.2.
3. Remove the right-side riser card assembly. For instructions, see “Removing a Riser Card Assembly”.
4. Remove the processor air duct. For instructions, see “Removing the Processor Air Duct”.
5. Note the location of the alignment notch. (“B”)
6. Insert the DIMM, making sure the connector edge of the DIMM aligns correctly with slot. (“E”)
7. Using both hands, push down firmly and evenly on both sides of the DIMM until it snaps into place and
the levers close.
(“C” and “D”)
IMPORTANT: Visually check that each latch is fully closed and correctly engaged with the notch on
the DIMM edge. (“E”)
8. Replace the air duct, riser card assembly, and the chassis cover if you have completed all work inside
of the server.
