Dynojet 248x: Installation Guide User Manual
Page 8

1 - 4
Document #98219101
Requirements to Unload Truck
When your dyno arrives, you must provide
equipment to unload the dynamometer from
the truck, with skids or forks a minimum of 6
inchs wide by 6 feet long. It must be capable
of lifting and moving at least 8000 pounds
(3642 KG).
The dyno has 2 C-Channels that run
lengthwise along the bottom of the dyno.
Unload the dynamometer using these
channels.
Requirements to Install the Dynamometer
Installation of the dynamometer requires
equipment capable of lifting and moving at
least 8000 pounds (3642 KG).
