Dynojet 248x: Installation Guide - Manual (Page 43)

Document #98219101 3 - 25
Step 6
Check the brakes. The DynoWare Stack must
be on to release the brakes. Slowly rotate the
drums (this can be done manually) then
press the brake button (the red button on the
Hand Held Pendant). The button should light
up and engage the brakes stopping the
drums. Press the button again and the light
will go off, disengaging the brake. If the
brakes do not engage, make sure the
pressure gauge Air Brake Regulator is set to
60 PSI (276 kPa), and check all connections.
If you have any installation questions, call
Dynojet at (800) 992-4993.
