Document #98219101 3 - 1
Chapter 3
Installing Dynamometer
Now that you have the dynamometer and the Four
Post Lift unpacked you may begin the installation..
Install Lift
Four Post Lift Installation
Refer to the installation guide of the Four
Post Lift for installation.
Install Dynamometer
After complete assembly of the Four Post
Lift, raise and lower the lift a few times to
insure proper operation. Whichever side of
the lift you choose to put the dynamometer
on, the short ramps on the lift must be
removed from that side.
Step 1
With the lift all the way down, move the dyno
into position. (Refer to the diagram in
Appendix A for the location of the dyno
relative to the lift)
