Dynojet 248x: Installation Guide User Manual

Page 28

3 - 10

Document #98219101

- The Data Acquisition Cable is coiled around

the Breakout Board. Uncoil the cable and

Plug the cable into the Pickup Card on the

dyno.

Note:

The rest of the instructions for wiring the
dyno follows the catwalk installation.
