Step 2

Thread the DynoWare Cable under the dyno

frame.

Proportional Air Step 3

Attach the center panel and tie up the cables

as shown below.

Standard Air Step 3

Attach all the side panels so that the Dynojet

Stickers face outward and the brake wires go

through a slot in the center panel as shown

below.
