Document #98219101 4 - 3

5. When the vehicle is positioned properly on the dyno, shut the

engine off.

• If the vehicle has an automatic transmission, place it in

park.

• If the vehicle has a manual transmission, place it in gear.

6. Set the vehicle’s emergency brake.

7. Secure the non-drive wheels using the provided tire chocks.

Do not use tire chocks for four wheel drive vehicles.

8. Attach the tie-down straps.

Rear Wheel Drive

• Attach two tie-down straps from secure anchor points to the

rear of the vehicle. Attach additional tie-down straps from
the rear of the vehicle as shown in Figure 5-2.

• Attach two tie-down straps from secure anchor points to the

front of the vehicle.

Front Wheel Drive

• Attach two tie-down straps from secure anchor points to the

rear of the vehicle.

• Attach two tie-down straps from secure anchor points to the

front of the vehicle. Attach additional tie-down straps
across the front of the vehicle to form a crisscross.

Four Wheel (All-Wheel) Drive

• Attach two tie-down straps from secure anchor points to the

rear of the vehicle. Attach additional tie-down straps across
the rear of the vehicle to form a crisscross.

• Attach two tie-down straps from secure anchor points to the

front of the vehicle. Attach additional tie-down straps
across the front of the vehicle to form a crisscross.

four wheel drive

front wheel drive

rear wheel drive
