Dynojet 248x: Installation Guide User Manual
Page 11

Document #98219101 1 - 7
Step 4
Verify the hardware contents as follows:
Brake Hardware:
• 2 brake weldments
(The following are attached to the dyno
frame)
• six 5/8" bolts
• six lock washers
• six flat washers
• six nuts
Mounting Hardware:
• 4- Foot Stands
• 4- 7/16” x 1” Bolts
• 4- 7/16” Flat Washers
• 4- 7/16” Lock Washers
• 4- 3/8” x 1” Bolts
• 4- 3/8” Flat Washers
• 4- 3/8” Lock Washers
• 4- Anchors
• 1- Set Tool
