Dynojet 248x: Installation Guide - Manual (Page 20)

3 - 2 Document #98219101
Step 2
Install the Feet on the four corners of the
dyno. Use the 7/16” x 1” bolts with flat and
lock washers to secure the feet to the dyno
frame. The bolts should be installed through
the slotted hole in the foot.
Do Not Tighten the Bolts.
Step 3
Once you have the four feet mounted to the
dyno, use a marker to mark the floor
mounting holes. When you have marked all
the holes, remove the feet.
The hardware should
go through the slotted
hole in the foot.
Mark the holes with
a felt tip marker.
