Document #98219101 A - 1
Appendix A
- Square the face of the dyno up to the face
of the four post lift. The distance between
the two is 4”.
Center Line of Dyno
and Four Post Lift
Lift Tube with
Roller Portion of
the Interface Kit
Relative Dyno and Four Post Lift Location
