Motorcycle Dynamometer Installation Guide
C H A P T E R 3
Monitor Arm
3-34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MONITOR ARM
This articulated arm and platform supports the monitor, keyboard, and mouse in a
convenient position for operation while seated on the motorcycle. The arm can be
mounted on either side of the dynamometer.
P ARTS L IST
The following table lists all of the parts included in the Monitor Stand Installation kit.
Check your kit against the parts listed to make sure you have received all of the parts.
If any part is missing, contact Dynojet Technical Support.
Part Number Description Quantity
21229300 Monitor Arm Tray 1
32391064 Bushing, 1" x 2", 10 Gauge, Stl 3
35521420 Plastic Cap, 1-3/4" x 1/2", Black 4
36701100 Nut, 1/2-13, Hex 2
36801253 Screw, 1/2-13 x 1-1/2", Sh-Cap 2
36932100 Washer, 3/8", Splitlock, Stl 1
36942100 Washer, 1/2", Splitlock, Stl 2
36943100 Washer, 1/2", Flat, Stl 4
61329100 Monitor Arm 2
61329102 Monitor Arm Base 1
61329103 Monitor Arm Upright 1
DM150-011-002 Washer, 3/8" Flat 1
DM150-011-006 Bolt, 3/8-16 x 1 1/4", Hex 1
