O P T I O N A L A C C E S S O R I E S
Air Brake
Version 3 Motorcycle Dynamometer Installation Guide
3-5
P ARTS L IST
The following table lists all of the parts included in the Air Brake (P/N 102-201)
Installation kit. Check your kit against the parts listed to make sure you have received
all of the parts. If any part is missing, contact Dynojet Technical Support.
part number description quantity
197104130 Zip Tie, 4” 6
22103080 Rod, Air Brake Spring 2
22923000 Spring Guide (retainer ring) 4
36390640 Bolt, 1/2-20 x 3/4, Hex 1
43310600 Grommet, 7/16” ID x 3/4” OD 1
61322300 Spring Bolt Mounting Plate 1
63990001 Caliper Assembly 1
63990002 Rotor/Taper Lock Assembly with Hub and Key 1
63990004 Air Cylinder Assembly 1
BR102-033 Grommet, 1”OD, 3/8ID, 3/4H, 1/8G 1
BR102-038-5 Air Hose Push Lock Fitting 1
BR102-038-6 Air Hose Bulk Head Fitting 1
BR102-038-7 Air Hose, 55” .05 55.00 inches
BR102-041 Master Cylinder 1
BR102-045 Brake Hose (installed) 1
None Copper Washers (installed) 2
BR102-046 Brake Line 1
BR102-047 Banjo Bolt (installed) 1
BR102-055 Springs, Purple (for Spring Bolt Assembly) 2
BR102-061 Bolts, 1/4 x 4 1/2”, Socket Head 2
DC100-104 Pendant and Cable 1
DE100-134 Screw, 8 x 1/2”, Self Tapping 2
DM150-035 1/2” Cable Clamp, Nylon 2
DM150-009-005 Nut, 1/4”, Adjuster (for Spring Bolt Assembly) 4
