Motorcycle Dynamometer Installation Guide
C H A P T E R 3
Extended Carriage
3-24
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EXTENDED CARRIAGE
The extended carriage option increases the maximum wheel base (measured from the
front of the front wheel to the center of the rear wheel) from 84 inches to 102 inches
for testing raked cruisers and drag bikes.
To prevent possible injury, disconnect the battery before performing any dyno
maintenance or installing any optional accessory.
P ARTS L IST
The following table lists all of the parts included in the Extended Carriage Installation
kit. Check your kit against the parts listed to make sure you have received all of the
parts. If any part is missing, contact Dynojet Technical Support.
part number description quantity
36488100 Nut, 3/8"-16, Nylock 6
36560834 Screw, 1/4-20 x 1/2", Button-head 2
DM150-002-008 Nut, 5/16" 4
DM150-011-002 Washer, 3/8", Flat 12
DM150-015-001 Nut Block 1
DM150-016-007 Carriage Screw Support Bracket 1
DM150-019-012 Bolt, 3/8 x 1", Hex 6
EXT100-206 Extended Carriage Support Bracket 1
EXT100-206
DM150-019
Carriage and Tire Stop 1
DM150-014-002 Small Leveling Shim 1
DM150-015-002 Large Leveling Shim 1
DM150-002-003 Bolt, 5/16 x 1 1/2" 4
DM150-002-004 Washer, 5/16", Lock 4
